LED Driver Replacement is a difficult process. When an LED fixture fails you need to either purchase a new fixture or replace the driver. In most scenarios it’s the LED driver that needs replacement (LED components have a longer shelf life).
LEDDOMAIN
Lighting
FOR TRAVELERS
TRIDONIC 87501147 Driver LC 30W 350-700mA DA SC SNC4
SALE PRODUCTS
Constant Voltage DALI Dimmer SR-2302P
* Pricing Available upon Request *
Product Description
The DALI Dimmer SR-2302P is a constant voltage dimming controller with 4 channel, 5A per channel output, which complies to standard DALI protocol with 1 DALI address to control 4 channels synchronously. The DALI dimmer is designed with newly updated outer shell which features easy connection terminal without screw to ensure easy and fast connection. The DALI address can be manually assigned and shown on the numeric digital display or automatically assigned by master controllers. 1 DALI address is available for 4 channels to work synchronously. 0%-100% smooth dimming can be achieved by the DALI dimmer via logarithmic dimming, which is perfect for human's vision. The DALI dimmer can be compatible with SR-2400TL, SR-2400TG, SR-2400TS, SR-2400LC, SR-2400GC, SR-2400SC and any other high quality DALI masters.

SRP-TRIAC-10CC
* Pricing Available upon Request *
Product Description
SRP-TRIAC-10CC is an ENEC approved 10W triac dimmable LED driver with 1 channel constant current output and adjustable current from 200mA to 350mA by DIP switches, which enables it to be suitable for different LED lights. It is designed with 200-240VAC input. The triac dimming driver is designed with DALI, Push, Triac, 0/1-10V 4 dimming interfaces in 1, which enables it to work with different control systems. The LED driver adopts amplitude dimming output instead of PWM output to ensure real flicker free. Power factor of the driver can be over 0.9 and efficiency is higher than 83%. It enables smooth and deep dimming to 1% without flickering and buzzing noise. 1 DALI address can be automatically assigned by DALI masters. Complying with IEC 62386-101, IEC 62386-102, IEC 62386-207, this DALI driver is compatible with most DALI systems in the market. The Triac dimming driver can be compatible with universal Triac dimmers. While selecting 0/1-10V interface, it is compatible with universal 0/1-10V dimmers.
Driver LC 10W 350mA fixC SR SNC2 10W 87500802 TRIDONIC
essence series
Product description
- Independent driver with strain-relief housing
- Extra flat housing for constrained installation conditions (small ceiling cut outs and low ceiling voids)
- Temperature protection as per EN 61347-2-13 C5e
- Output current 250, 350, 500 or 700 mA
- Max. output power 10 W
- Nominal lifetime up to 50,000 h
- 5 years guarantee
Driver LC 53W 1130–1200mA 0-10V fixC lp SNC UNV 53W 87500861 TRIDONIC
Linear essence series (US applications)
Product description
- Constant current LED driver
- Only for US applications
- Dimmable via 0 ... 10 V
- Dimming range 10 to 100 %
- Class 2
- FCC Part 15
- Meets UL 8750 SF3.1
- Meets DesignLights Consortium 4.3
- Temperature protection as per UL8750/UL Recognized
- Adjustable output current 1,130 or 1,200 mA
- Max. output power 53 W
- Nominal lifetime up to 50,000 h
- 5 years guarantee
LEDDOMAIN
ALUMINIUM PROFILE MANUFACTURER
The LED strip light's adhesive backing inside the aluminum channel, snap on the diffuser cover. Rigidly build anodized aluminum material, better heat dissipation, providing great protection for delicate LED strip lights. This kit includes the aluminum led channel, PC Opal diffuser, end caps and mounting clips , pre assembled plug & play connectors . Standard length 1m , 2m , 3m , customization option available as per project requirement .
