LED Driver Replacement is a difficult process. When an LED fixture fails you need to either purchase a new fixture or replace the driver. In most scenarios it’s the LED driver that needs replacement (LED components have a longer shelf life).
LEDDOMAIN
Lighting
FOR TRAVELERS
TRIDONIC 87501147 Driver LC 30W 350-700mA DA SC SNC4
SALE PRODUCTS
Driver LCA 75W 100–400mA one4all lp PRE 75W 28000657 TRIDONIC
premium series non-SELV
Product description
- NEW: lumDATA (DALI-2 part ext. 251, 252 and 253)
- Dimmable built-in constant current LED driver
- Output current adjustable between 100 – 400 mA
- Dimming range 1 to 100 %
- For luminaires of protection class I and protection class II
- Max. output power 75 W
- Up to 92 % efficiency
- Power input on stand-by < 0.15 W
- Nominal lifetime up to 100,000 h
- 5 years guarantee
SR-2303P
* Pricing Available upon Request *
Product Description
The DALI Dimmer SR-2303P is a constant voltage dimming controller with 4 channel, 5A per channel output, which complies to standard DALI protocol with 4 DALI addresses to control 4 channels separately. The DALI dimmer is designed with newly updated outer shell which features easy connection terminal without screw to ensure easy and fast connection. The DALI address can be manually assigned and shown on the numeric digital display or automatically assigned by master controllers. 4 DALI addresses are available for 4 channels to work separately. 0%-100% smooth dimming can be achieved by the DALI dimmer via logarithmic dimming, which is perfect for human's vision. The DALI dimmer can be compatible with SR-2400TL, SR-2400TG, SR-2400TS, SR-2400LC, SR-2400GC, SR-2400SC and any other high quality DALI masters.
SRPC-2309PRO-24-200CVF
* Pricing Available upon Request *
Product Description
With the maximum output power of 200W, this 4-in-1 200W DALI DT8 LED Driver is in compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2, IEC 62386-209:2011. Featured with built-in DALI-2 interface and 4-channel 12VDC/24VDC constant voltage output, this device has a full isolated metal casing. Its PF is greater than 0.98 and its efficiency is greater than 93%. For this LED driver, 4 universal device types: primary N, Tc, XY coordinate and RGBW, can be set by the buttons. Besides, only 1 address is required to control 4 outputs separately under primary N mode. This driver is suitable for indoor LED lighting applications with 5-year warranty.
Driver LCA 10W 150–400mA one4all SC PRE 10W 28000673 TRIDONIC
premium series
Product description
- NEW: lumDATA (DALI-2 part ext. 251, 252 and 253)
- Dimmable built-in constant current LED driver
- Can be either used built-in or independent with clip-on strain-relief (see accessory)
- Dimming range 1 to 100 %
- For luminaires of protection class I and protection class II
- Output current adjustable between 150 – 400 mA via ready2mains Programmer, I-SELECT 2 plugs or DALI
- Max. output power 10 W
- Up to 82 % efficiency
- Power input on stand-by < 0.2 W
- Nominal lifetime up to 100,000 h
- 5 years guarantee
Driver LC 60W 24V one4all lp PRE 60W 28003521 TRIDONIC
premium series 24 V – dimmable (IP20) Product description
- NEW: lumDATA (Luminaire data, Energy reporting and Diagnostics & Maintenance)
- Dimmable 24 V constant voltage LED driver for flexible constant voltage strips
- one4all interface enables different dimming options
- Dimming range 1 to 100 %
- No additional external dimmer is needed
- Suitable for emergency escape lighting systems acc. to EN 50172
- Nominal lifetime up to 50,000 h
- 5 years guarantee
LEDDOMAIN
ALUMINIUM PROFILE MANUFACTURER
The LED strip light's adhesive backing inside the aluminum channel, snap on the diffuser cover. Rigidly build anodized aluminum material, better heat dissipation, providing great protection for delicate LED strip lights. This kit includes the aluminum led channel, PC Opal diffuser, end caps and mounting clips , pre assembled plug & play connectors . Standard length 1m , 2m , 3m , customization option available as per project requirement .
