LED Driver Replacement is a difficult process. When an LED fixture fails you need to either purchase a new fixture or replace the driver. In most scenarios it’s the LED driver that needs replacement (LED components have a longer shelf life).
LEDDOMAIN
Lighting
FOR TRAVELERS
TRIDONIC 87501147 Driver LC 30W 350-700mA DA SC SNC4
SALE PRODUCTS
30W DALI LED Driver (Constant Voltage) SRP-2305-24-30CV
* Pricing Available upon Request *
Product Description
This 100W DALI DT8 Dimmable LED Driver is in compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2, IEC 62386-209:2011, and compatible with universal DALI masters that support DT8 commands. With built-in DALI2 interface, this DALI DT8 device is controlled via a single DALI address. Moreover, this device is equipped with 2-channel DC 24V constant voltage output and high power factor and efficiency. Its dimming method is PWM, with smooth and deep dimming to 0.1%. Besides, this driver has error report function, and supports DALI DT8 Tc type. Its protection grade is IP20, which is suitable for indoor LED lighting applications, with 5-year warranty.
Driver LCBI 10W 180mA PHASE-CUT/1–10V SR 10W 87500273 TRIDONIC
advanced series
Product description
- Independent dimmable LED driver
- Constant current LED driver
- Dimmable via leading edge and trailing edge phase dimmers
- Dimmable via 1 ... 10 V
- Output dimmed analogue (current amplitude)
- Dimming range typ. 10 to 100 % (depending on dimmer)
- For luminaires of protection class I and protection class II
- For luminaires with M and MM as per EN 60598, VDE 0710 and VDE 0711
- Temperature protection as per EN 61347-2-13 C5e
- SELV
- Output current 180, 350 or 500 mA
- Output power 10 W
- Nominal lifetime up to 50,000 h
- 5 years guarantee
Driver LC 75W 250–550mA flexC lp EXC 75W 28001808 TRIDONIC
excite series non-SELV
Product description
- Constant current LED driver for luminaire installation
- For luminaires of protection class I and protection class II
- Adjustable output current between 250 and 550 mA via ready2mains Programmer or I-SELECT 2 plugs
- Max. output power 75 W
- Up to 94 % efficiency
- Nominal lifetime up to 100,000 h
- 5 years guarantee
SRP-TRIAC-10CC
* Pricing Available upon Request *
Product Description
SRP-TRIAC-10CC is an ENEC approved 10W triac dimmable LED driver with 1 channel constant current output and adjustable current from 200mA to 350mA by DIP switches, which enables it to be suitable for different LED lights. It is designed with 200-240VAC input. The triac dimming driver is designed with DALI, Push, Triac, 0/1-10V 4 dimming interfaces in 1, which enables it to work with different control systems. The LED driver adopts amplitude dimming output instead of PWM output to ensure real flicker free. Power factor of the driver can be over 0.9 and efficiency is higher than 83%. It enables smooth and deep dimming to 1% without flickering and buzzing noise. 1 DALI address can be automatically assigned by DALI masters. Complying with IEC 62386-101, IEC 62386-102, IEC 62386-207, this DALI driver is compatible with most DALI systems in the market. The Triac dimming driver can be compatible with universal Triac dimmers. While selecting 0/1-10V interface, it is compatible with universal 0/1-10V dimmers.
LEDDOMAIN
ALUMINIUM PROFILE MANUFACTURER
The LED strip light's adhesive backing inside the aluminum channel, snap on the diffuser cover. Rigidly build anodized aluminum material, better heat dissipation, providing great protection for delicate LED strip lights. This kit includes the aluminum led channel, PC Opal diffuser, end caps and mounting clips , pre assembled plug & play connectors . Standard length 1m , 2m , 3m , customization option available as per project requirement .
