LED Driver Replacement is a difficult process. When an LED fixture fails you need to either purchase a new fixture or replace the driver. In most scenarios it’s the LED driver that needs replacement (LED components have a longer shelf life).
LEDDOMAIN
Lighting
FOR TRAVELERS
TRIDONIC 87501147 Driver LC 30W 350-700mA DA SC SNC4
SALE PRODUCTS
SR-SBP2801K4-BLE
* Pricing Available upon Request *
Product Description
SR-SBP2801-BLE enables the realization of energy harvesting wireless switches for lighting, build- ing or industrial automation control systems using Bluetooth® low energy technology.
SR-SBP2801-BLE is mechanically compatible with existing switch elements enabling quick integration into a wide range of designs. Key applications are wall-mounted or portable switches either with up to two rockers or up to four push buttons.
SR-SBP2801-BLE pushbutton transmitters are self-powered (no batteries) and fully maintenance- free. They can therefore be used in all environments including locations that are difficult to reach or within hermetically sealed housings. The required energy is generated by an electro-dynamic energy transducer actuated by an energy bow located on the left and right of the module. This energy bow which can be pushed from outside the module by an appro- priate pushbutton or switch rocker.
When the energy bow is pushed down or released, electrical energy is created and a radio telegram according to the Bluetooth® low energy standard is transmitted. This radio telegram transmits the status of all four contact nipples when the energy bow was pushed down or released. SR-SBP2801-BLE radio telegrams are protected with AES-128 security based on a device-unique private key.
SR-SB9101SAC-HP
* Pricing Available upon Request *
Product Description
The SR-SB9101SAC-HP is an innovative AC phase dimmer with Bluetooth mesh and RF control interface. The Bluetooth dimmer is designed with 1 00-24-0VAC wide input and output, channel and maximum 400W output. The Bluetooth dimmer switch is available with both  easing edge dimming version and trailing edge dimming version for choosing. The  innovative minimum brightness setting function enables users to set a minimum brightness and dim from this minimum brightness to 100% brightness.
Driver LC 50W 700mA fixC lp SNC 50W 87500447 TRIDONIC
essence series non-SELV Product description
- Fixed output built-in LED driver
- Constant current LED driver
- For luminaires of protection class I and protection class II
- Temperature protection as per EN 61347-2-13 C5e
- Output current 250, 300, 350, 700 or 1,050 mA
- Max. output power 50 W
- Nominal lifetime up to 50,000 h
- 5 years guarantee
Driver LC 10W 350mA fixC SC SNC2 10W 87500796 TRIDONIC
essence series
Product description
- Fixed output LED driver
- Can be either used built-in or independent with clip-on strain-relief (see accessory)
- Independent LED driver with cable clamps
- Constant current LED driver
- For luminaires of protection class II
- Temperature protection as per EN 61347-2-13 C5e
- Output current 250, 350, 500 or 700 mA
- Max. output power 10 W
- Nominal lifetime up to 50,000 h
- 5 years guarantee
LEDDOMAIN
ALUMINIUM PROFILE MANUFACTURER
The LED strip light's adhesive backing inside the aluminum channel, snap on the diffuser cover. Rigidly build anodized aluminum material, better heat dissipation, providing great protection for delicate LED strip lights. This kit includes the aluminum led channel, PC Opal diffuser, end caps and mounting clips , pre assembled plug & play connectors . Standard length 1m , 2m , 3m , customization option available as per project requirement .
