Specifications
| Part No. | Input Voltage | Output Current | Output Power | Output type | Dimension (mm) |
|---|---|---|---|---|---|
| SR-2303S | 12-36VDC | 1CH, 8A/CH | 96-288W | Constant Voltage | 33*82*20 |
Product Dimension
Wiring Diagram
1 Channel Constant Voltage DALI Dimmer SR-2303S
AED0.00
* Pricing Available upon Request *
The DALI Dimmer SR-2303S is a mini size constant voltage LED dimming controller with 1 channel 8A per channel output, which complies with standard DALI protocol with 1 DALI address to control 1 channel separately. The DALI address will be automatically assigned by master controllers. 1 DALI address is available for 1 channels work separately. 0%-100% smooth dimming can be achieved by the DALI dimmer via logarithmic dimming, which is perfect for human’s vision.
Key Features
- DALI certified
- TUV CE certified
- Constant voltage DALI LED dimmer with 1 channel, 8A per channel output available in 12VDC, 24VDC and 36VDC output.
- In accordance with DALI standard protocol IEC 62386-102, IEC 62386-207 and in compliance with DALI products from other international incorporation.
- DALI address will be automatically assigned by master controller.
- 1 DALI address, 1 channel work separately.
- 0%-100% dimming range via logarithmic characteristic, perfect for human’s vision.
- To work with LED lights to establish DALI lighting system.
- To work with power repeater to expand output unlimitedly.
Description
Reviews (0)
Shipping & Delivery
Data Sheets
Related products
RGBW DT8 DALI Dimmer SR-2309FA-RGBW
* Pricing Available upon Request *
Product Description
SR-2309FA-RGBW is a 4 channel constant voltage RGBW DT8 DALI dimmer that complies to the latest IEC 62386-209:2011 standard and supports DT8 device commands. Color control is as defined in the DALI specification for device type 8, color type RGBW or XY coordinates can be preset by factory setting. All output channels of this device is controlled via a single DALI address and it is compatible with universal DALI master controllers that supports DT8 commands. DT8 commands enable easy RGB color adjusting. DALI address can be manually assigned and displayed via digital display. It is configurable via DALI software tool and DALI USB interface.
Constant Voltage DALI Dimmer SR-2304BEA
* Pricing Available upon Request *
Product Description
The DALI Dimmer SR-2304BEA is a constant voltage dimming controller with 4 channel, 8A per channel output, which complies to standard DALI protocol with 1 DALI address to control 4 channels synchronously. The DALI address can be manually assigned and shown on the numeric digital display or automatically assigned by master controllers. 1-4 DALI addresses can be configurable for 4 channels to work synchronously or separately. 0.1%-100% smooth dimming can be achieved by the DALI dimmer via logarithmic dimming, which is perfect for human's vision. The DALI dimmer can not only be compatible with DALI masters, but also push switch to get dim and switch functions under the situation without DALI signal.
4 Channels DALI DT8 Dimmer with Built-in Master Function SR-2309FA-OLED
* Pricing Available upon Request *
Product Description
Product Description
SR-2309FA-OLED is the world first DALI certified DT8 dimmer with built-in DALI master function and OLED display for visible manual configuration. The LED dimmer is designed with 4 PWM outputs which are controlled via a single DALI address. DT8 color types all in one: Tc, RGBWA, XY+ Tc, RGB+ Tc can be set. It enables to address (00-63) and group (0-15) the dimmer. It enables to predefine and recall total 16 DALI scenes to the dimmer. PWM output frequency can be set from 250Hz-30KHz which ensures ultra smooth color control.
It enables to set a Min. level for dimming between this level to Max. level. Output level and DT8 color can be set manually. DALI default parameters such as fade time, fade rate, power on level, system failure level can be set .
DALI Dimmable Driver(1 channel) SR-2303S
* Pricing Available upon Request *
Product Description
The DALI Dimmer SR-2303S is a mini size constant voltage LED dimming controller with 1 channel 8A per channel output, which complies with standard DALI protocol with 1 DALI address to control 1 channel separately. The DALI address will be automatically assigned by master controllers. 1 DALI address is available for 1 channels work separately. 0%-100% smooth dimming can be achieved by the DALI dimmer via logarithmic dimming, which is perfect for human's vision.
Constant Voltage DALI Dimmer SR-2304B
* Pricing Available upon Request *
Product Description
The DALI Dimmer SR-2304B is a constant voltage dimming controller with 4 channel, 5A per channel output, which complies to standard DALI protocol with 1 DALI address to control 4 channels synchronously. The DALI address can be manually assigned and shown on the numeric digital display or automatically assigned by master controllers. 1-4 DALI addresses can be configurable for 4 channels to work synchronously or separately. 0.1%-100% smooth dimming can be achieved by the DALI dimmer via logarithmic dimming, which is perfect for human's vision. The DALI dimmer can not only be compatible with DALI masters, but also push switch to get dim and switch functions under the situation without DALI signal.
Constant Voltage DALI Dimmer SR-2302B(WP)
* Pricing Available upon Request *
Product Description
The DALI Dimmer SR-2302B is a constant voltage dimming controller with 4 channel, 5A per channel output, which complies to standard DALI protocol with 1 DALI address to control 4 channels synchronously. The DALI address can be manually assigned and shown on the numeric digital display or automatically assigned by master controllers. 1 DALI address is available for 4 channels to work synchronously. 0%-100% smooth dimming can be achieved by the DALI dimmer via logarithmic dimming, which is perfect for human's vision.
30W DALI LED Driver(Constant Voltage) SRP-2305-24-30CV
* Pricing Available upon Request *
Product Description
Product Description
This 1-channel 24VDC constant voltage output DALI LED Driver is in compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2. With built-in DALI-2/Push interface and class Ⅱ power supply, this DALI DT6 device has  full isolated plastic case. Besides, with built-in active PFC function, its PF > 0.9 and its efficiency > 86%. This driver’s dimming method is PWM digital dimming, with standard DALI logarithmic dimming curve. Moreover, it is compliant with Safety Extra Low Voltage standard, coupled with over load, over temperature protection. Its protection grade is IP20, which is suitable for indoor LED lighting applications, with 5-year warranty.
Mini Size Constant Voltage DALI & PUSH Dimmer SR-2303 (Push Dim)
* Pricing Available upon Request *
Product Description
This DALI & PUSH dimmer is a DALI-2, CE and FC certified device, coupled with 12-24VDC power input. This device is in compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2, and can match all DALI systems in the market, so that you can rest assured to use it. With one DALI address input and one channel output, this dimmer is mini in size, high in output current, and its current is 10A per channel. Moreover, its dim function can directly support AC high voltage input PUSH switch. This product has both DALI dimmer and PUSH dimmer functions while connected with DALI master controllers and AC PUSH switches respectively.
