LED Driver Replacement is a difficult process. When an LED fixture fails you need to either purchase a new fixture or replace the driver. In most scenarios it’s the LED driver that needs replacement (LED components have a longer shelf life).
LEDDOMAIN
Lighting
FOR TRAVELERS
TRIDONIC 87501147 Driver LC 30W 350-700mA DA SC SNC4
SALE PRODUCTS
SR-2102BEA
* Pricing Available upon Request *
Product Description
The SR-2102BEA is a constant voltage DMX512 decoder with 3 channel or 4 channel selectable, 8A per channel output and available in 12VDC, 24VDC and 36VDC output. The DMX512 decoder is designed with DMX512 compliant control interface, which enables users to set DMX address freely and shows the address on digital numeric display. The DMX decoder can be compatible with SR-2811DMX, SR-2201DMX, SR-2812, SR-2816 and any other high quality DMX masters.
Driver LCBI 15W 350/500/700mA BASIC phase-cut lp 15W 89800257 TRIDONIC
advanced series
Product description
- Dimmable via leading edge and trailing edge phase dimmers
- Output dimmed analogue (current amplitude)
- Dimming range typ. 5 to 100 % (depending on dimmer)
- Type of protection IP20
- Push-in terminals
- Connecting cable, wire cross-section 0.5 – 1.5 mm²
- SELV
- 350, 500 or 700 mA output current
- Output power 15/16 W
- Nominal lifetime of 50,000 h (at max ta 50 °C with a failure rate ≤ 0.2 % per 1,000 h)
- 5 years guarantee
SR-2300TS-DIM-EU Black
* Pricing Available upon Request *Â
Product Description
The SR-2300TS-DIM is a touch control dimmer switch with DALI output which complies to standard DALI protocol to dim and switch 4 light zones. Each DALI bus can install multiple dimmer switches. The high strength tempered glass panel offers smooth dimming and switch functions without any flickering. The LED dimmer complies to standard DALI protocol and can be compatible with DALI products from other international corporations. The DALI master can control up to 4 zones with 3 scenes saved for each zone. Available in standard European size and US size as well, the dimmer switch can be installed easily. Compatible with most of our DALI slaves that available in constant voltage and constant current versions, the DALI touch dimmer switch can control different types of LED lighting.
This DALI controller is available with both 100-240VAC input and 12-24VDC input versions. AC input version is designed with built-in 100mA DALI power supply to power up to 50 DALI ECG and it can also be powered by DALI bus while not connected to AC mains. Max. 100 DALI ECG can be controlled by 4 AC input DALI touch panels via broadcast on a control circuit with 2 connected to AC mains and 2 powered by DALI bus.
Driver LC 44W 1050mA fixC pc SR SNC2 44W 28003347 TRIDONIC
essence series
Product description
- Dimmable constant current LED driver (SELV)
- Independent driver with strain-relief housing
- Extra flat housing for constrained installation conditions (small ceiling cut outs and low ceiling voids)
- Dimmable via leading edge and trailing edge phase dimmers
- Dimming range 5 to 100 % (depending on dimmer)
- For luminaires with F or M and MM as per EN 60598, VDE 0710 and VDE 0711
- Max. output power 44.1 W
- Output current 1,050 mA
- Nominal lifetime up to 50,000 h
- 5 years guarantee
LEDDOMAIN
ALUMINIUM PROFILE MANUFACTURER
The LED strip light's adhesive backing inside the aluminum channel, snap on the diffuser cover. Rigidly build anodized aluminum material, better heat dissipation, providing great protection for delicate LED strip lights. This kit includes the aluminum led channel, PC Opal diffuser, end caps and mounting clips , pre assembled plug & play connectors . Standard length 1m , 2m , 3m , customization option available as per project requirement .
